| Specifications |
| I/O Interface |
| Power | Input: DC 12-55V |
| Ethernet | ۸ * ۱۰/۱۰۰/1000M RJ45 Ports |
| ۲ * ۱۰/۱۰۰/1000M SFP Ports |
| Performance |
| Switching Capacity | 20Gbps |
| Forwarding Rate | ۱۴.88Mpps |
| MAC Address | 4K |
| Jumbo Frame | 9216bytes |
| Transfer Mode | Store and forward |
| MTBF | ۱۰۰۰۰۰ hours |
| Standard |
| Network protocol | IEEE802.3 |
| IEEE802.3u |
| IEEE802.3ab |
| IEEE802.3z |
| IEEE802.3x |
| Industry Standard | EMI: FCC Part 15 CISPR (EN55032) class A |
| EMS: EN61000-4-2 (ESD) |
| EN61000-4-4 (EFT) |
| EN61000-4-5 (Surge) |
| Network Medium | 10BASE-T: Cat 3, 4, 5 UTP(≤۱۰۰ meter) |
| 100BASE-TX: Cat5 or more UTP (≤۱۰۰ meter) |
| 1000Base-TX: Cat5 or more UTP/STP(≤۱۰۰ meter) |
| Protection |
| Certificate | CE, FCC, RoHS |
| Environment4 |
| Environment | Working Temperature: -40~75°C |
| Storage Temperature: -40~85°C |
| Working Humidity : 10%~90%, non-condensing |
| Storage Temperature: 5%~90%, non-condensing |
| Working Height: Maximum 10, 000 feet |
| Storage height: Maximum 10, 000 feet |
| Physical Features |
| Dimension | Product Dimension (L*W*H): 160*135*44mm |
| Package Dimension (L*W*H): 242*207*86mm |
| N.W: 0.73kg |
| G.W: 0.90kg |
| Packing Info | Carton MEAS: 445*445*510mm |
| Packing Qty: 20 units |
| Packing Weight: 19KG |
| Power Voltage | Input Voltage: DC 12-55V |
| Type of input: 4 PIN Industrial Terminal(block V1+V1- V2+ V2-) |
| Package List | Switch 1 pcs, Pull-arm 1 pair, User manual 1 pc, Certification 1 pc |
| Indicators |
| PWR(power supply) | Lighting: Powered |
| Un-Light: No Power |
| ۱-۱۰ Green(Link&Data) | Lighting: Connecting |
| Flashing: Data Transmit |
| Un-Light: Disconnect |
