| Specification |
| I/O Interface |
| Power | Input: AC 100-240V, 50/60Hz |
| Ethernet | ۴* ۱۰/۱۰۰/۱۰۰۰M PoE ports + 2* Gigabit SFP ports |
| Performance |
| Switching Capacity | ۱۲Gbps |
| Forwarding Rate | ۸.۹۲۸Mpps |
| Packet Buffer | ۱Mb |
| MAC Address | ۲K |
| Jumbo Frame | ۹۲۱۶bytes |
| Transfer Mode | Store and forward |
| MTBF | ۱۰۰۰۰۰ hours |
| Standard |
| Network protocol | IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x |
| PoE Protocol | IEEE802.3af (15.4W) |
| IEEE802.3at (30W) |
| Industry Standard | EMI: FCC Part 15 CISPR (EN55032) class A |
| EMS: EN61000-4-2 (ESD) |
| EN61000-4-4 (EFT) |
| EN61000-4-5 (Surge) |
| Network Medium | ۱۰BASE-T: Cat 3,4,5 UTP(≤۱۰۰ meter) |
| ۱۰۰BASE-TX: Cat5 or more UTP (≤۱۰۰ meter) |
| ۱۰۰۰Base-TX : Cat5 or more UTP/STP(≤۱۰۰ meter) |
| Optical Media | Multimode fiber: ۵۰/۱۲۵, ۶۲.۵/۱۲۵, ۱۰۰/۱۴۰um |
| Single mode fiber: ۸/۱۲۵, ۸.۷/۱۲۵, ۹/۱۲۵, ۱۰/۱۲۵um |
| Protection |
| Certificate | CE、FCC、RoHS |
| Environment |
| Environment | Working Temperature: -10~50°C |
| Storage Temperature: -40~85°C |
| Working Humidity: 10%~90%，non-condensing |
| Storage Temperature: 5%~90%，non-condensing |
| Working Height: Maximum 10,000 feet |
| Storage height: Maximum 10,000 feet |
| Physical Features |
| Dimension | Product Dimension (L*W*H): ۲۰۰*۱۱۸*۴۴mm |
| Package Dimension (L*W*H): ۲۴۵*۱۹۰*۶۰mm |
| N.W: 0.6kg |
| G.W: 0.9kg |
| Packing Info | Carton MEAS: 505*320*400mm |
| Packing Qty: 20 units |
| Packing Weight: 19KG |
| Power Voltage | Input Voltage : AC 100-240 V |
| Power supply: 52V2.3A |
| Package List | Switch 1 pcs, Power cord 1 pcs, User manual 1 pc, Certification 1 pc |
| Indicators |
| DIP Switch | VLAN: Port isolation mode. In this mode, the PoE ports (1-4) of the switch cannot communicate with each other, and can only communicate with the UP-link port |
| Default: Normal mode, all port can communicate with each other, the transmission distance is within 100 meters, the transmission rate is 10M / 100/1000M adaptive |
| Extend: Link extension mode, 3-4 ports PoE power supply and data transmission distance can be extended to 250 meters, the transmission rate becomes 10M |
| LEDs | PWR(power supply)，Mode(DIP)，۱-۶(Link&Data) |
